| MODEL | Bearing Type | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Acoustic Noise | Life expectancy | |||
| PART NO. |
SIGNAL |
B.T.S.R |
VDC |
VDC |
Amp |
Watt |
R.P.M. |
m³/min |
CFM |
mmH₂O |
IN H₂O |
dB-A |
hours |
| DBTB0428_2M | -FG / RD | B | 12 | 7.0 to 13.2 | 0.18 | 2.16 | 12000 | 0.378 | 13.36 | 27.08 | 1.066 | 44.22 | 70000 |
| DBTB0428_2H | -FG / RD | B | 12 | 7.0 to 13.2 | 0.32 | 3.84 | 15000 | 0.480 | 16.95 | 34.65 | 1.364 | 49.07 | 70000 |
| DBTB0428_2U | -FG / RD | B | 12 | 7.0 to 13.2 | 0.40 | 4.80 | 17000 | 0.537 | 18.97 | 42.72 | 1.682 | 51.82 | 70000 |
| DBTB0428_2S | -FG / RD | B | 12 | 7.0 to 13.2 | 0.43 | 5.16 | 19000 | 0.610 | 21.53 | 49.47 | 1.948 | 54.23 | 70000 |
| DBTB0428_2F | -FG / RD | B | 12 | 7.0 to 13.2 | 0.60 | 7.20 | 20500 | 0.664 | 23.43 | 56.71 | 2.233 | 55.85 | 70000 |
| DBTB0428_2G |
-FG / RD | B | 12 | 7.0 to 13.2 | 0.85 |
4.92 |
24000 |
0.778 |
27.46 |
64.97 |
2.558 |
59.28 |
70000 |
| Product P&Q Curve Dimension Drawing | |||||||||||||
|
|
|||||||||||||
