| MODEL | Bearing Type | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Acoustic Noise | Life expectancy | |||
| PART NO. | SIGNAL | B.T.S.R | VDC | VDC | Amp | Watt | R.P.M. | m³/min | CFM | mmH₂O | IN H₂O | dB-A | hours |
| DBPN0428_2U | -FG / RD | B | 12 | 7.0 to 13.2 | 1.50 | 18.0 | 25000 | 0.892 | 31.51 | 107.02 | 4.213 | 65.6 | 70000 |
| Product P&Q Curve Dimension Drawing | |||||||||||||
| |||||||||||||
