| MODEL | Bearing Type | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Acoustic Noise | Life expectancy | |||
| PART NO. |
SIGNAL |
B.T.S.R |
VDC |
VDC |
Amp |
Watt |
R.P.M. |
m³/min |
CFM |
mmH₂O |
IN H₂O |
dB-A |
hours |
| DBPE0428_2M | -FG / RD | B | 12 | 7.0 to 13.2 | 0.38 | 4.56 | 15000 | 0.544 | 19.20 | 36.23 | 1.426 | 52.5 | 70000 |
| Product P&Q Curve Dimension Drawing | |||||||||||||
|
|
|||||||||||||
