| MODEL | Bearing Type | Rated Voltage | Operating Voltage | Current | Input Power | Speed | Air Flow | Air Pressure | Acoustic Noise | Life expectancy | |||
| PART NO. |
SIGNAL |
B.T.S.R |
VDC |
VDC |
Amp |
Watt |
R.P.M. |
m³/min |
CFM |
mmH₂O |
IN H₂O |
dB-A |
hours |
| DAZB0210_5U | -FG | R | 5 | 4.5 to 5.5 | 0.30 | 1.50 | 17000 | 0.0535 | 1.89 | 7.78 | 0.306 | 25.1 | 50000 |
| DAZB0210_5H | -FG | R | 5 | 4.5 to 5.5 | 0.25 | 1.25 | 13000 | 0.0453 | 1.42 | 4.65 | 0.179 | 21.4 | 50000 |
| DAZB0210_5M | -FG | R | 5 | 4.5 to 5.5 | 0.15 | 0.75 | 9000 | 0.0300 | 0.94 | 2.23 | 0.087 | 18.2 | 50000 |
| Product P&Q Curve Dimension Drawing | |||||||||||||
|
|
|||||||||||||
